eatures

• High online efficiency: Reduces utlility costs, generates less heat.
• Green mode: Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
• Pure sine wave output on battery: Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
• LCD Status Display: Provides key UPS status at a glance. Multiple status indicators with load and battery bar graphs.
• Cold-start capable: Provides temporary battery power when the utility power is out.
• Temperature-compensated battery charging: Prolongs battery life by regulating the charge voltage according to battery temperature.

Availability

• Boost and Trim Automatic Voltage Regulation (AVR): Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
• Intelligent battery management: Maximizes battery performance, life, and reliability through intelligent, precision charging.
• Power conditioning: Protects connected loads from surges, spikes, lightning, and other power disturbances.
• Temperature-compensated battery charging: Prolongs battery life by regulating the charge voltage according to battery temperature.
• Automatic restart of loads after UPS shutdown: Automatically starts up the connected equipment upon the return of utility power.
• Automatic self-test: Periodic battery self-test ensures early detection of a battery that needs to be replaced.
• Disconnected battery notification: Warns when a battery is not available to provide backup power.

Manageability

• Network manageable: Provides remote power management of the UPS over the network.
• Audible alarms: Actively let you know if the unit is on battery, if the battery is low or if there is an overload condition.
• LED status indicators: Quickly understand unit and power status with visual indicators.
• Serial connectivity: Provides management of the UPS via a serial port.
• USB connectivity: Provides management of the UPS via a USB port (not available on all models).
• Disconnected battery notification: Warns when a battery is not available to provide backup power.

Serviceability

• User-replaceable batteries: Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
• Hot-swappable batteries: Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
• Predictive failure notification: Provides early-warning fault analysis ensuring proactive component replacement.
• Resettable circuit breakers: Enables a quick recovery from overload events.
• Battery failure notification: Provides early-warning fault analysis on batteries enabling timely preventive maintenance

Adaptability

• Adjustable voltage-transfer points: Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
• Adjustable voltage sensitivity: Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.

Safety

• Safety-agency approved: Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Technical Specifications

Output

• Output Power Capacity: 2100 Watts / 3000 VA
• Max Configurable Power: 2100 Watts / 3000 VA
• Nominal Output Voltage: 230V
• Output Voltage Distortion: Less than 5% at full load
• Output Frequency (sync to mains): 50 Hz
• Topology: Line Interactive
• Waveform Type: Sine wave
• Output Connections: (6) IEC 320 C13, (1) IEC 320 C19

Input

• Nominal Input Voltage: 230V
• Input Frequency: 47 - 63 Hz
• Input Connections: IEC-320 C20
• Input voltage range for main operations: 180 - 287V
• Input voltage adjustable range for mains operation: 170 - 300V

Batteries & Runtime

• Battery Type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
• Typical recharge time: 3 hour(s)
• Replacement Battery
  (Service center technician only): APCRBC151
• Replacement Battery: RBC7
• RBC
